Peripheral Blood Smear Evaluator

First time user? Read me.

45 year old African American male from the internal medicine service.The automated differential flagged for platelet clumps.

WBC: 7.2 X10^3/mm3 (4.5-11.0)
RBC: 2.54 X10^6/mm3 (4.50-5.90)
HCT: 24.1 % (40.0-51.0)
HBG: 8.4 gm/dl (13.5-17.5)
MCV: 94.9 fl (80.0-100.0)
MCH: 33.2 pg (26.0-34.0)
MCHC: 34.9 gm/dl (31.0-37.0)
Platelet Count: 96 X10^3/mm3 (130-400)
RDW: 27.7 % (11.5-14.5)

Automated Differential
Lymphocytes: 12
Monocytes: 12
Neutrophils: 74
Eosinophils: 2
Basophils: 0

Your name:

Highly Significant Finding	up to 1%	1-2.5%	>2.5%
Polychromasia	1+	2+	3+
Basophilic Stippling	1+	2+	3+
Howell Jolly Bodies	1+	2+	3+
Pappenheimer Bodies	1+	2+	3+
Acanthocytes Irregular spaced	1+	2+	3+
Blister Cells	1+	2+	3+
Schistocytes / Fragments	1+	2+	3+
Sickle Cells	1+	2+	3+
Spherocytes	1+	2+	3+
Tear Drop Cells	1+	2+	3+

Lower Significance Finding	5-25%	25-50%	>50%
Microcytes	1+	2+	3+
Macrocytes	1+	2+	3+

Hypochromasia	1+	2+	3+
Target Cells	1+	2+	3+
Burr Cells (evenly spaced)	1+	2+	3+
Ovalocytes	1+	2+	3+
Stomatocytes	1+	2+	3+

The RBC Morphology trainer is a learning tool that has been used in the LSU Health Sciences Center Clinical Laboratory Science curriculum. For this evaluation study, participant performance data is de-identified before being analyzed. Your internet protocol address is not captured by this application. The application does not use your mail client to submit the data. All participants are anonymous to the study. By proceeding, you are consenting to allow your data to be included in the study.
